Custom UL Defrost PVC Insulation Heating Wire Cable Heater

Short Description:

The PVC heating wire cable diameter have 2.5mm, 3.0mm,4.0mm,etc.The defrost heating wire color have tranparent,white,pink,red.The length of defrost wire heater can be customized as required.


Product Detail

Product Tags

Product Configuration

PVC defrost heating wire cable is a common electric heating element, usually used for low temperature heating occasions. It is composed of electric heating wire (such as nickel chromium alloy) and PVC insulation layer, with good flexibility, corrosion resistance, excellent insulation properties and other characteristics.

The common defrost PVC heating wire has 105°C insulation material, which can withstand high temperatures, and is suitable for refrigerator freezer compensation heating and medical equipment. We offer heating wires of different diameters, single or double layer PVC insulation at 105 ° C. The heating cable consists of resistance wire wrapped around a fiberglass bracket and PVC covered in an outer layer, which can be protected if necessary with a metal braided layer (for grounding) or with a protective sleeve.

Product Paramenters

Porduct Name PVC Heating Cable
Insulation Material PVC
Wire diameter 2.5mm,3.0mm,4.0mm,etc.
Heating length customized
Lead wire length  1000mm,or custom
Color white,grey,red,blue,etc.
MOQ 100pcs
Resistant voltage in water 2,000V/min (normal water temperature)
Insulated resistance in water 750MOhm
Use defrost heating wire
Certification  UL
Company supplier/factory/manufacturer

The defrost PVC heating wire length,voltage and power can be customized as required.The wire diameter can be choosed 2.5mm,3.0mm,3.5mm,and 4.0mm.The wire surface can be braided firberglass,aluminum or stainless steel.

The defrost wire heater heating part with lead wire connector can be seal with rubber head or double-wall shrinkable tube,you can choose according to your own use needs.

Fiberglass braid

Stainless/Aluminum Braid

PVC Heater Wire

Silicone Heating Wire

1.Voltage: usually 12V, 24V, 36V, 110V or 220V.

2. Power: Depending on the length and line diameter, the power range is wide (such as 10W/m to 50W/m).

3. Temperature range: The general operating temperature is -30°C to 105°C.

4. Wire diameter: Common wire diameter is 2mm to 6mm.

Product Features

Flexibility

PVC heating cable is soft and flexible, suitable for heating needs of various shapes.

Corrosion resistance

PVC outer layer has good chemical corrosion resistance, suitable for wet or corrosive environment.

Insulation properties

PVC material has good insulation and can effectively prevent leakage.

Low temperature heating

Suitable for low temperature heating (usually below 100°C).

Low cost

The price is relatively low, economical and practical.

Product Applications

1. Household appliances: such as electric blankets, heating pads, pet heating pads, etc.

2. Industrial equipment: used for pipeline insulation, equipment antifreeze, constant temperature control, etc.

3. Agriculture: Used for greenhouse heating, soil heating, etc.

4. Medical equipment: such as physiotherapy equipment, thermal blankets, etc.

drain pipe heater1

Factory Picture

drain pipe heater
aluminum foil heater
drainpipe band heater
defrosting wire heater

Production Process

1 (2)

Service

fazhan

Develop

received the products specs,drawing,and picture

xiaoshoubaojiashenhe

Quotes

the manager feedback the inquiry in 1-2hours and send quotation

yanfaguanli-yangpinjianyan

Samples

Free samples will be sent for check products quality before bluk production

shejishengchan

Production

confirm products specification again,then arrange the production

dingdan

Order

Place order once you confirmed samples

ceshi

Testing

Our QC team will be checked the products quality before delivery

baozhuangyinshua

Packing

packing products as required

zhuangzaiguanli

Loading

Loading ready productsto client’s container

receiving

Receiving

Received you order

Why Choose Us

•   25 years exporting & 20 years manufacturing experience
   Factory covers an area of about 8000m²
   In 2021,all kinds of advanced production equipment had been replaced, including powder filling machine, pipe shrinking machine, pipe bending equipment, etc.,
•   the average daily output is about 15000pcs
   Different Cooperative customer
•   Customization depend on your requirement

Certificate

1
2
3
4

Related Products

Defrost Heater

Oven Heating Element

Aluminum Tube Heater

Aluminum Foil Heater

Crankcase Heater

Drain Line Heater

Factory Picture

aluminum foil heater
aluminum foil heater
drain pipe heater
drain pipe heater
06592bf9-0c7c-419c-9c40-c0245230f217
a5982c3e-03cc-470e-b599-4efd6f3e321f
4e2c6801-b822-4b38-b8a1-45989bbef4ae
79c6439a-174a-4dff-bafc-3f1bb096e2bd
520ce1f3-a31f-4ab7-af7a-67f3d400cf2d
2961ea4b-3aee-4ccb-bd17-42f49cb0d93c
e38ea320-70b5-47d0-91f3-71674d9980b2

Before the inquiry,pls send us below specs:

1. Sending us the drawing or real picture;
2. Heater size,power and voltage;
3. Any special requirements of heater.

Contacts: Amiee Zhang

Email: info@benoelectric.com

Wechat: +86 15268490327

WhatsApp:  +86 15268490327

Skype: amiee19940314
