| Porduct Name | Defrosting freezer aluminum foil heater |
| Humidity State Insulation Resistance | ≥200MΩ |
| After Humid Heat Test Insulation Resistance | ≥30MΩ |
| Heating parts material | PVC heating wire or silicone heating wire |
| Shape | Customized |
| Size | Customized |
| Lead wire length | customized |
| Resistant voltage in water | 2,000V/min (normal water temperature) |
| Terminal model | customized |
| Use | defrost Heating Element |
| Base material | Metal |
| Protection class | IP00 |
| Approvals | CE |
|
The difference of aluminum foil heater heating parts: 1. PVC heating wire: The maximum temperature resistance of PVC heating wire is 108 ° C, while the temperature resistance of silicone wire can reach -60 ° C to 200 ° C. The PVC wire itself is relatively hard, the surface is smooth, the price is cheap, and the heating part and the lead line can be sealed by high-frequency welding or heat shrink sleeve. 2. Silicone rubber heating wire: Silicone rubber heating wire is more soft, anti-aging performance is outstanding, long service life, wide range of use. The heating part and the lead line can be sealed by silicone molding, which has better water resistance. Among them, if the aluminum foil heating sheet uses PVC heating wire, it can be made by the mold machine, and the wiring of the aluminum foil heater will be more accurate and beautiful. Silicone heating wire can only be produced by hand laying. |
|
Defrost Heater
Heating Wire
Drain Line Heater
The Defrosting Freezer Aluminum Foil Heater can be customized shape and size as customer's requirements.The aluminum foil heater heaing parts we'll used the PVC heating wire or silicone rubber heating wire.The foil heater wire diameter we'll use 2.5mm,3.0mm,or other required diameter.
The wire place can be designed as customer's requirements and the voltage is 12-230V.
The aluminum foil heater is mainly used for defrosting and fog removal of refrigerator door frame and defrosting effect of water tray, and can also be used for food insulation effect such as warm cutting board and rice cooker.
Before the inquiry,pls send us below specs:
1. Sending us the drawing or real picture;
2. Heater size,power and voltage;
3. Any special requirements of heater.
