Product Configuration
Defrost aluminum tube heaters are specialized defrosting heating devices used in refrigerators, cold storage facilities, and other equipment. They are made by encapsulating electric heating elements in aluminum tubes or aluminum alloy casings, achieving rapid defrosting through efficient heat conduction. The key design features include the following points:
1. Heating element: Embedded with resistance wire (such as iron-chromium-aluminum wire) and a glass fiber core inside, and wrapped with a silicone rubber insulation layer on the outside to ensure sealing and prevent leakage of electricity;
2. Aluminum tube shell: Made of aluminum alloy tube, with fins or fixed plates attached to the surface to increase the heat dissipation area and improve defrosting efficiency;
3. Temperature control: Some models are integrated with a temperature control module, featuring high temperature uniformity, thorough defrosting and low energy consumption.
Product Paramenters
| Porduct Name | Fridge Antifreezing Defrost Aluminum Tube Heater |
| Humidity State Insulation Resistance | ≥200MΩ |
| After Humid Heat Test Insulation Resistance | ≥30MΩ |
| Humidity State Leakage Current | ≤0.1mA |
| Surface Load | ≤3.5W/cm2 |
| Tube diameter | 4.5mm,6.5mm,etc. |
| Shape | customized |
| Resistant voltage | 2,000V/min |
| Insulated resistance | 750MOhm |
| Use | Aluminum Defrost Heater |
| Tube length | 300-7500mm |
| Lead wire length | 700-1000mm (custom) |
| Approvals | CE/ CQC |
| Terminal type | Customized |
|
Jingwei heater is the Fridge Antifreezing Defrost Aluminum Tube Heater factory,the aluminum heating tube specification can be customized as client’s drawing or samples.At present, we have produced several aluminum defrost heater mainly exported to Egypt and other Middle Eastern countries, if you need to contact us. |
|
Features
Quick-defrosting and energy efficiency
1. High thermal conductivity of aluminum can quickly melt frost, shorten downtime and ensure continuous operation of equipment ;
2. The energy consumption is reduced by about 35% compared with the traditional heating pipe, which is suitable for high frequency use scenarios such as commercial cold storage .
Durability and safety
1. Aluminum alloy shell corrosion resistance, high temperature resistance, longer life than ordinary metal ;
2. Silicone rubber insulation layer and sealing structure to prevent leakage, in line with industrial safety standards .
Adaptability and flexibility
1. The aluminum defrost heater support custom size (such as fin spacing, pipe diameter), suitable for different brands of refrigerators (such as Haier, Rongsheng, Mitsubishi) ;
2. The aluminum heater tube can be installed in evaporator, condenser and other key parts, suitable for household refrigerator to large cold storage
Product Application
*** Household refrigerator : Solve the frost problem in the cold room/freezer room, extend the life of the equipment (such as Rongsheng BCD-563WY series) ;
*** Commercial cold storage : with 304 stainless steel evaporator, efficient removal of thick frost layer, ensure refrigeration efficiency ;
*** Cold chain equipment : the aluminum tube heater used for display cabinets, refrigerated trucks and other scenes, to maintain low temperature environmental stability .
JINGWEI Wokshop
Production Process
Service
Develop
received the products specs,drawing,and picture
Quotes
the manager feedback the inquiry in 1-2hours and send quotation
Samples
Free samples will be sent for check products quality before bluk production
Production
confirm products specification again,then arrange the production
Order
Place order once you confirmed samples
Testing
Our QC team will be checked the products quality before delivery
Packing
packing products as required
Loading
Loading ready productsto client’s container
Receiving
Received you order
Why Choose Us
• 25 years exporting & 20 years manufacturing experience
• Factory covers an area of about 8000m²
• In 2021，all kinds of advanced production equipment had been replaced, including powder filling machine, pipe shrinking machine, pipe bending equipment, etc.,
• the average daily output is about 15000pcs
• Different Cooperative customer
• Customization depend on your requirement
Certificate
Related Products
Aluminum Foil Heater
Immersion Heater
Defrost Heater
Defrost Wire Heater
Silicone Heating Pad
Drain Line Heater
Factory Picture
Before the inquiry,pls send us below specs:
1. Sending us the drawing or real picture;
2. Heater size,power and voltage;
3. Any special requirements of heater.
